Small and Easy to carry
High Capacity Portable Generator

PORTABLE POWER STATION

12-36V portable power station are Lithium Iron Phosphate (LiFePO4)Battery
with compatible SLA (Sealed Lead Acid)battery housing.

MULTIFUNCTIONAL OUTPUTS

1.The AC output of camping battery has been upgraded to 110V/330W(Peak 700W).

2. It features 3* USB-A ports, 1*Type-C and DC car ports to power many equipments such as phone, laptop, light, fan, mini cooler and so on with pure sine wave inverter.

3. 12V DC Ports: 2*DC 12V/5A and 1*DC 12V/10A.
Maxworld portable power station
QC 3.0 USB
30min
0 %
QC 2.0 USB
30min
0 %
Normal Charge

30min

0 %

FASTER USB OUTPUTS

Charging more devices at the same time-faster More Efficient
3*QC3.0 USB 1*type-C Port

IphoneX (2716mah)
27 Recharges

Iраd мini (23.8 wh)
11.5 Rесhаrgеs

Gopro Hero5 (4.9wh)
56 Recharges

Mini Fan (2000mah)
37 Recharges

SPECIFICATIONS

MODEL Max330 Max500 Max1000
Rated power 330W 500W 1000W
Rated capacity 288.6WH 519WH 799.2WH
Standard capacity 3.7V/78000
mAh
3.7V/140400
mAh
3.7V/216000
mAh
Overload protection 360±20W 530±20W 1040±30W
Ac output 240V±10%
/50HZ
110V±10%
/60HZ
240V±10%
/50HZ
Output waveform pure sine wave
USB output QC3.0/18W
Output Type-C QC3.0/60W PD60W PD60W
Lighter output 12V/10A 14V/8A 14V/8A
DC55*2.1 output 12V/5A 14V/8A 14V/8A
Wireless charger 5W 10W 10W
Charging input voltage 12-24V 12-26V 12-26V
Working temperature -10℃ ~ 40℃
Weight
(net weight)
≈3.3kg ≈4.8kg ≈6kg
Weight
(including accessories)
≈4.3kg ≈5.8kg ≈7kg
Product size 205*155*165
mm
290*194*200
mm
290*194*200
mm
LED light Super Brightness LED Panel
Design Extreme Compact Powerful Design
Built-in Battery 100% A Grade Lithium battery
Cycle life above 800times
Charging Mode CC/CV
Output port Custom accordingly to different countries
Operation Humidity 10%~90%
Built-in Perfect MPPT function
Various Colour options red, orange, yellow, blue, purple
Power Indicator LED Display
Protection type Intelligent BMS selif-balancing system
Cooling function Intelligent Cooling system
Include Full Productions Short Circuit, Overload, over charge, over current, over voltage, over discharge, over temp protections, Anti-protections
(AC output standard American gauge, Japanese gauge support custom China gauge,European, Australian, etc.)
Accessories Brown paper and yellow box
The charger
1* car charger cable
Solar charging wire
User guide
Packing specification Single machine packing color box 295*195*210
mm Outer dimensions of finished large cartons: length, width and height 615*410*250
mm Four in a box 20GP:1620PCS 40GP:3420PCS
The color box is 380mm long, 262mm wide and 258mm high Outer dimensions of finished large cartons: length, width and height 540*397*286
mm, B: Two in a box 20GP:800PCS 40GP:1760PCS
The color box is 380mm long, 262mm wide and 258mm high Outer dimensions of finished large cartons: length, width and height 540*397*286
mm, B: Two in a box 20GP:800PCS 40GP:1760PCS
Datasheet

Feature

•LARGE CAPACITY
Comparing to similar portable electric generators, Maxworld portable generator possesses 78000mAh/288.6Wh power capacity.

•3 WAYS OF CHARGING
Maxworld solar portable power station generator can be fully recharged in 5-8H from the sun with compatible 100W solar panel (not included).With built-in MPPT solar charge controller, it can be charged efficiently. The portable power source can be fully charged in only 5-6 hours via being plugged into wall outlet. With car charger, you can full charge battery backup by car socket in 7-8H. There are other flexible recharging ways like generator.

•TEMPTING ADVANTAGE OF GENERATOR
1.The top of the camping generator is designed as a wireless charger that means you can use our camping battery as a wireless charger.
2.Updated LED light with SOS mode, large irradiation area and radial light ray feature can protect eyes and Illuminate a broad field of vision.
3.Silica gel anti-collision strip protect portable power station generator all-round.
4. solid handle helps easy carry and easy operate wherever you go.
5.Pure sine wave inverter safely protect electronic device.

•SILENT GENERATOR WITH REASSURING SAFETY
With pure lithium battery and pure sine wave inverter, Maxworld portable CPAP generator works faster, quieter and stable. Without gasoline or toxic fumes, camping portable power station is completely healthy &eco-friendly. Battery Management System (BMS) provides temperature control, voltage control &more excellent safety operation to protect your devices.

About this item

WHAT YOU GET:
You will receive 1* Maxworld 330Wh Portable Power Station, 1* car charger cable, 1* charger, 1* solar charging wire, 1* user guide, 2 year customer service. For a better customer experience, we will optimize the product from time to time.

Reliable and Powerful Backup Power Supply

Maxworld portable power station
Maxworld portable power station
It is powerful enough to recharge smartphone 27 times, Mini Tablet 11.5 times, and Floodlight 56 times when it’s fully charged. Perfect mobile power station for home / camping / CPAP / laptop / cameras / drones.
Maxworld portable power station
Maxworld pride us on our excellent R&D team and strong creativity, with the most advanced facilities, strict ISO standard manufacturing process, efficient management, and the awareness of being a leader in battery industry, committed to manufacturing and design LiFePO4 and lithium batteries and integrated battery packs for green energy storage systems. Focusing on lead-acid batteries to replace green energy, and provide best battery solutions for solar energy storage systems, 48V systems for telecommunication stations, 12 or 24V marine and RV energy systems and so on.
