Telecom Solar ESS Energy Storage System

Maxword Power 48V series Lithium Iron Phosphate Battery
is storage battery to provide reliable backup power systems.

Telecom Solar ESS Energy Storage System

Built-in intelligent BMS (Battery Management System) for battery protection from overcharge, over-discharge, overcurrent and over-temperature.

Standard 19-inch rack-mount durable enclosure for plug & play replacement

Equipped with RS485/RS232 communication

Built-in function for parallel connection

Standard BMS with options for charging current limit in parallel connection (programmable ON/OFF)

Safest lithium chemistry with high energy density

Efficient & long-lasting service life

SPECIFICATIONS

Model ES4850X ES4850 ES48100X ES48100 ES4810X ES4810
General Characteristics
Nominal voltage 48V 51.2V 48V 51.2V 48V 51.2V
Nominal [email protected] 50Ah 50Ah 100Ah 100Ah 12Ah 12Ah
Min. [email protected] 48.5Ah 48.5Ah 97 Ah 97Ah 11.5Ah 11.5Ah
Nominal energy 2.4kwh 2.56kWh 4.8kWh 5.12kWh 576Wh 614.4Wh
Dimensions(W*D*H) 483*400*133mm 483*400*133mm 483*385*222mm 483*385*222mm 483*373*44mm 483*373*44mm
Approx, weight 30.3 Kg 31.5Kg 49.5Kg 51.8Kg 9Kg 9.2Kg
Electrical Characteristics
Operating voltage range 42V~54V 44.8V~57.6V 42V~53.2V 44.8V~56.8V 42V-53.2V 44.8V~56.8V
Recommended charging voltage 52.5V-54V 56V~57.6V 52.5V~53.2V 56V~56.8V 52.5V 56V
Max. charging current 50A 50A 50A 50A 5A 5A
Charging current limit in parallel connection (programmable ON/OFF) 10A 10A 10A 10A 2A 2A
Max. continuous discharging current 50A 50A 50A 50A 10A 10A
Max. peak discharging current 55A (<3S) 55A (<3S) 55A(<3S) 55A(<3S) 12A(<3S) 12A(<3S)
Discharging cut-off voltage 42V 44.8V 42V 44.8V 42V 44.8V
Faraday charging efficiency N98% 298% 298% 298% >98% >98%
Energy charging efficiency N92% 292% 292% 292% >92% >92%
Internal resistance 80mQ 85mQ 55mQ 60m Q 140mQ 150mQ
Self-discharge <3.5% <3.5% <3.5% <3.5% <3.5% <3.5%
Cycle Life (@25°C,0.2C,80%DOD) 1800 Cycles 1800 Cycles 1800 Cycles 1800 Cycles 1800 Cycles 1800 Cycles
Operating Conditions
Operating temperature Charge 0°C-45°C 0°C~45°C 0°C~45°C
Discharge -10°C~45°C -10°C~45°C -10°C~45°C
Storage temperature -20°C~45°C -20°C~45°C -20°C~45°C
Storage duration 12 Months @20°C~25°C 12 Months @20°C~25°C 12 Months @20°C~25°C
Safety standard UL1642 at cell level UL 1642 at cell level UL1642 at cell level
Water dust resistance IP30 IP30 IP30
Parallel function Maximum support 16 units in parallel, recommended no more than 12 units Maximum support 16 groups in parallel, recommended no more than 12 groups Maximum support 16 units in parallel, recommended no more than 12 units
Datasheet

Electric Power Systems

The Electric Power Systems also has corresponding information and control systems in various links and different levels to measure, regulate, control, protect, communicate and dispatch the production process of electric energy, so as to ensure that users can obtain safe and high-quality electric energy.

Telecom ESS Energy System

Unattended Power Source

Maxworld Power 48V series Lithium Iron Phosphate Battery is storage battery to provide reliable backup power for access network equipment, remote switch, mobile communications, transmission equipment and other Telecom Solar ESS Energy Storage System.
